    Modular Digital Advertising Display Screens , Hd LED Video Wall 104X104 P

    Ask Lasest Price
    Brand Name : BST
    Model Number : IRA-3
    Certification : CE,RoHs, FCC, ISO9001
    Price : Negotiation
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 5000sq.meter / Month
    Delivery Time : 10-20 days after receive payment
    • Product Details
    • Company Profile

    Modular Digital Advertising Display Screens , Hd LED Video Wall 104X104 P

    Modular Digital Advertising Display Screens , Hd LED Video Wall 104X104 P



    Digital Advertising Display Screens Parameters


    Digital Advertising Display Screens SPECIFICATION
    IRA-2XIRA-2IRA-3IRA-4
    Physical Pitch2.6mm2.973.914.81
    Pixel ConfigurationSMD2121SMD2121SMD2121SMD2121
    Pixel Density147,456 pixels/sqm112,896 pixels/sqm65,536 pixels/sqm43,264 pixels/sqm
    Module Dimensions
    (WXH)(mm)
    250X250250X250250X250250X250
    Panel Dimensions(mm)500X500X75 /
    500X1000X75
    500X500X75 /
    500X1000X75
    500X500X75 /
    500X1000X75
    500X500X75 /
    500X1000X75
    No. of Modules Per
    Panel(WXH)
    2X2/2X42X2/2X42X2/2X42X2/2X4
    Physical Resolution
    of Module(WXH)
    96X9684X8464X6452X52
    Physical Resolution
    of Panel(WXH)
    192X192/ 192X384168X168/ 168X336128X128/ 128X256104X104/ 104X208
    Panel MaterialDie-Casting AluminumDie-Casting AluminumDie-Casting AluminumDie-Casting Aluminum
    Single Cabinet
    Weight
    8/14kg/panel8/14kg/panel8/14kg/panel8/14kg/panel
    Processing16bit16bit16bit16bit
    Colours281 trillion281 trillion281 trillion281 trillion
    Contrast Ratio4,000:14,000:14,000:14,000:1
    Average Power
    Consumption
    64/128 W/panel64/128 W/panel64/128 W/panel64/128 W/panel
    Max Power
    Consumption
    192/384 W/panel192/384 W/panel192/384 W/panel192/384 W/panel
    Operation Temp/
    Humidity
    —10℃-60℃ /10%-60%—10℃-60℃ /10%-60%—10℃-60℃ /10%-60%—10℃-60℃ /10%-60%
    Storage Temp/
    Humidity
    —30℃-60℃ /10%-60%—30℃-60℃ /10%-60%—30℃-60℃ /10%-60%—30℃-60℃ /10%-60%
    Refresh Rate>1920Hz>1920Hz>1920Hz>1920Hz
    Brightess≥1,200nits≥1,200nits≥1,200nits≥1,200nits
    Horizontal Viewing
    Angle
    160°160°160°160°
    Vertical Viewing
    Angle
    140°140°140°140°
    Expected Lifetime100,000Hrs100,000Hrs100,000Hrs100,000Hrs
    Max Stacking20/1020/1020/1020/10
    Max Hanging20/1020/1020/1020/10
    ServicingFront/RearFront/RearFront/RearFront/Rear
    IP Rationg
    (Front/Rear)
    IP 40/IP21IP 40/IP21IP 40/IP21IP 40/IP21
    CertificationCCC,CE,ETL,ROHSCCC,CE,ETL,ROHSCCC,CE,ETL,ROHSCCC,CE,ETL,ROHS

    Digital Advertising Display Screens Application:

    Entertainment events,Commercial advertising,Stadium perimeter, such as banks,schools, telecommunications, mobile media, night club, business establishments, customs, stadiums, studio, stock exchange centers, bus station, shopping malls, railways, airports, harbors, etc;
