    Ultral HD P1.6 SMD1010 Indoor Advertising Led Display For Tv Studio / Trade Show

    Ask Lasest Price
    Brand Name : BST
    Model Number : BST-IA1.6
    Certification : CE,FCC, CCC, Rohs,ISO
    Price : Negotiation
    Payment Terms : T/T, Western Union, L/C
    Supply Ability : 5000sqm per month
    Delivery Time : 10- 20 days
    • Product Details
    • Company Profile

    Ultral HD P1.6 SMD1010 Indoor Advertising Led Display For Tv Studio / Trade Show

    Ultral HD P1.6 SMD1010 Indoor Advertising Led Display For Tv Studio / Trade Show


    Quick Detail:

    1, It usually use 1/30 scanning to turn down the brightness.

    2, First Class SMD1010 3 in 1 Epistar LEDs

    3, Die casting alumminum cabinet ,0.1mm gapline between
    4, The module size: 129*145mm,Standard Cabinet size 516*345mm
    5, High flatness.Random dismantling, convenient maintenance;

    6, Fast locks design, cabinets can be easily assemblied in 5 seconds

    7, Ghost-free image;


    Description:

    (1) PH1.6mm is the smallest pixel pitch for indoor full color LED video display, which has high definition with big pixel density 385,776dots/sqm and large pixels with good and clear image.

    (2) Multiplied file formats, such as VGA, Video, AVI, MOV, MPG, DAT, VOB etc. and also we have three display modes as VGA and DVI. There are also interfaces for Sound signal and video signal.
    (3) 4096 grade grey control system and the color are over 4.4trillion.

    (4) Show all kinds of word, text, graph, picture, video, 2-dimention, 3-dimention cartoon and other information with your PC does synchronously.
    (5)
    Customized design is available,OEM & ODM are welcomed.
    (6) Can be connected with PC and the web net and show the content, and also can be controlled remotely via VPM+ADSL.


    Applications:

    We have a proven track record in the high-end TV studio market; rock solid, flicker free, on-camera performance with full greyscale at low brightnesses.


    Competitive Advantage:

    • The SMD (3-in-1) LED package provides wider viewing angles and extremely close viewing distances.

    • Advanced video processing produces crystal-clear, detailed images with smooth motion reproductions.

    • Image feeds delivered in both standard and high-definition formats.

    • Full-depth image calibration in the factory and in the field provides for a uniform display picture.

    • Integrates seamlessly with a variety of other BST video products

    • Area distributor enjoys special discount and protection of sales area.

    • 2 Years guarantee. Only charge for cost of repair after 2 years.

    • Exclusive and unique solution can be provided by our well-trained and professional engineers and staffs.

    • BST offer oversea technical support by well-trained engineers if clients required. The relevant costs charge by clients.


    Specification:


    BST-IA1.6mm (Indoor HD Led Display For P1.6mm)

    Pixel configuration

    SMD1010 1R1G1B 3 in 1

    LEDs configuration

    Red:wave length: 625~630nm;300-400mcd

    Green:wave length: 525~530nm;600-800mcd

    Blue:wave length: 470~475nm;100-150mcd

    Pixel pitch(mm)

    1.6

    Pixel density(dots/sqm)

    385776

    Calibrated brightness(cd/sqm,nit)

    600 nits(adjustable)

    Calibrated brightness proportion ratio

    R: G: B = 30%:60%:10%

    Color temperature

    3,500° ~ 9,500° K(adjustable)

    Contrast ratio

    4,500:1

    Brightness adjustment(dimming)

    100 grade auto/manual-adjustment

    View angle(degree)(50% brightness)

    Horizontal: 140° (70° off center); Vertical: 140° (70° off center)

    Readability viewing angle

    Horizontal/ Vertical: 160° (80° off center)

    Color capability

    4.4 trillion

    Refresh rate(Hz)

    >1500 Hz

    Frame frequency(Hz)

    >60 Hz

    Interface port

    DVI interface(DVI connector)

    Input signal

    VGA, Video, AVI, MOV, MPG, DAT, VOB etc.

    Protection grade

    IP40

    LED Drive

    Constant-current drive

    Lifetime(hours)(50% brightness)

    100,000 hours

    Signal transmission direction

    Horizontal

    Operation humidity(RH)

    10-95%

    Servicing

    Rear serving optional

    Control mode

    Synchronous & asynchronous available

    Communication options

    Wire Ethernet, Fiber Ethernet,RF wireless,GPRS

    Power

    120/240 V AC single phase(50-60Hz)

    Maximum power consumption(W/SQM)

    1000

    Average power consumption(W/SQM)

    400

    Screen operation mode(scan/static)

    1/30

    Module configuration(Pixels quantities of the module)

    Length

    80

    Height

    90

    Module dimensions(mm)

    Length

    129

    Height

    145

    Cabinet dimensions(mm)

    Length

    516

    Height

    345

    Width

    85

    Recommend Optimal Viewing Distance: Minimum & Maximum

    Min

    1.6

    Max

    38

    Packing material

    Wooden case/flight case(optional)
