    Indoor P6 Full Color convex/concave Curved LED Display screen SMD3528 IP43 for advertising

    Ask Lasest Price
    Brand Name : BST
    Model Number : BST-IFC-6
    Certification : CE,RoHS, FCC, ISO
    Price : Negotiation
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 5000sq.meter / Month
    Delivery Time : 10~20 days after receive payment
    • Product Details
    • Company Profile

    Indoor P6 Full Color convex/concave Curved LED Display screen SMD3528 IP43 for advertising

    Indoor P6 Full Color convex/concave Curved LED Display screen SMD3528 IP43 for advertising


    Poducts Description:


    1, Inner or outer curve 0-15 degreen, seamless connection

    2. Strong quality control and R&D ability

    3. High anti-aging material, as well as high protection level, which makes it perfect for any complicated application

    4. 140 degree Wide viewing angle

    5. Professional flight plugs, stable and safe

    6. Anti-corrosion, oxidation resistance, long life span

    7, High brightness, and can be adjustable, meets the need of changing requirement
    of customer in environment.

    8, 2 year warranty and good after-sale service

    9, Lower requirement of Steel structure, 35% structure cost saved

    10, Penetrating design without light penetration, no harm to contrast ration, full conservated the display effect

    11, Low voltage and power consumption

    12,Optional of Convex Shaped, Concave Shaped and Wave Shaped screens etc.

    13,Curve degrees can be adjusted accordingly to different requests of architectural design

    14,Extremely narrow gap between modules contributes to clear image and smooth transition between modules without interval.


    Applications:


    Commercial advertising, Luxor hotel, railways, airports, harbors, night club, business establishments, such as banks, customs, stadiums, studio, stock exchange centers, bus station, schools, telecommunications,

    shopping malls, etc;


    Specifications:

    1. Indoor LED Display Technical Parameter


    Model No.

    BST-IFC-6

    Maximum Power Consumption

    1000W/m2

    Module Size

    192mm×192mm

    Out of Control Rate0.01 %

    Grey Scale

    10bits/1024levels

    Pixel Density

    27777 dots/m2

    Cabinet Size960×960×135mm

    Graphics Card

    DVI Graphics Card

    InstallationWall mount, hung and stand structure

    Pixel Configuration

    1R1G1B

    Refresh Frequency>1500HZ

    Waterproof Level

    IP43

    Operating Temperature

    Static:-40°C~+85°C Working:-20°C~+60°C

    LED Lifespan100,000 hours

    Brightness

    ≥1500cd/cd2

    Contrast

    ≥2000:1

    Minimum Viewing Distance

    6m

    Color Capability

    16777216

    Color Temperature

    5000-9300K

    Average Power consumption

    300W/m2

    Working Voltage

    AC 220V/110V s±15% 50-60 HZ

    Pixel Pitch6mm

    Frame Frequency

    60-85HZ

    Drive Mode

    Dynamic 1/8 Duty Constant Current

    Brightness Correction

    Pixel, Module, Cabinet Correction

    Operating Humidity

    10-90% RH

    MTBF

    ≥50,000 hours

    Computer Operation System

    Win 98/ Win XP/ Win 2000/Win 8

    Video Signal Input

    RF,S-Video,RGB,RGBHV,YUV,YC,VGA, DVI, HDMI, SDI,HD-SDI ,Composite

    Video Signal Output

    RF, S-Video, GB, RGBHV, YUV, YC etc.

    Viewing Angle

    140°(Horizontal )/140°(Vertical )

    Cabinet Resolution192dots×192dots

    Control System

    LINSN OR DB-STAR

    Software

    LED studio 10.0

    Module Resolution(Pixel)

    32dots×32dots

    LED TypeSMD 3 in 1

    Wavelength (R.G.B)

    R:625±2nm G:525±2nm B:470±2nm

    Control Distance


    UTP CAT5E:100m Multi-mode Fiber:500m Single-mode Fiber:10km

    Indoor P6 Full Color convex/concave Curved LED Display screen SMD3528 IP43 for advertising


    Indoor P6 Full Color convex/concave Curved LED Display screen SMD3528 IP43 for advertising

    Indoor P6 Full Color convex/concave Curved LED Display screen SMD3528 IP43 for advertising

    Indoor P6 Full Color convex/concave Curved LED Display screen SMD3528 IP43 for advertisingIndoor P6 Full Color convex/concave Curved LED Display screen SMD3528 IP43 for advertising


    Service

    1)Reply your inquiry in 24 hours.


    2)Experienced staffs answer all your query in fluent English,Spanish,Russian,etc

    3)Customized design is available,OEM & ODM are welcomed.

    4)Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staffs.

    5)Special discount and protection of sales area provided to our led display distributor.

    6)Warmly welcome your visit in our company if available


    Aftersales service

    √ Two years quality warranty with lifelong led display maintenance.


    √ Free guarantee repair (including labor and material): free for repair service in quality warranty period and reasonable charge for spare parts and maintaining service after the quality warranty period. Never exempt our responsibilities on product owned defects, modules, power supply, who set led display all repair.


    √ Spare Parts and free CAD drawing : necessary 2% spare parts are provided together with products to customers.
    √ Free Technical Training : integrative and normative technology training is available for free to technical personnel from customer, to ensure trainees to be skilled in regular operation of hardware and software of the products, and be able to estimate and solve small problems, synchronizatrion assitance for led screen.


    √ Customer Investigation : our after-sales team will telephone or e-mail user every month in warranty period to follow up the working condition of the products, and to discover problem and solve the problem instantly.


    √ Software Upgrade : lifelong maintenance of control system, incessant improvement on the system functions and unending software upgrades, now we used Linsn or Nova control system


    √ Site Instruction Service of installation is available.
