    P16 Curtain Led Display Screen With Transparent Panels For Stage / Event / Advertising

    Ask Lasest Price
    Brand Name : BST
    Model Number : BST-TS-16
    Certification : CE,FCC, CCC, Rohs,ISO
    Price : Negotiation
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 5000sqm per month
    Delivery Time : 10 - 20 days after receive payment
    • Product Details
    • Company Profile

    P16 Curtain Led Display Screen With Transparent Panels For Stage / Event / Advertising


    P16 Curtain Led Display Screen With Transparent Panels For Stage / Event / Advertising


    Quick Detail:


    1) Made up of High quality material. Transparent, flexible.Ultra light & think like paper;
    2) Easy to use, the controller & signal cable all hidden on the tope together with the control box. So look front the LED screen body, it is very clean and tidy.
    3) The screen come out with the power plug.
    4) Resolution is customized.
    5) Size is customized.


    Description:


    1. Transparent body: Transparent LED give more amazing screen
    2.Light weight: Ultra-slim and ultra-lightweight bring more design opportunities and save the shipping cost
    3.Amazing flexibility: can be designed many different shapes.
    3.High brightness: High-quality RGB 3-IN-1 LED, brings bright, high-impact, full-color video images.



    Applications:

    It looks like a crystal curtain to bring more creative application. It is applied in fashion shows, trade shows, theme parks, music concerts, visual stage, shopping mall advertising, video wall, indoor decoration and more.

    Specifications:

    1. LED Display Technical Parameter

    Model No.

    BST-TS-16

    Pixel Pitch

    16mm

    Module Size

    480mm*320mm

    Module Resolution (W*H)

    30dots*20 dots

    Pixel Density

    3906dots/ ㎡

    LED Type

    SMD3528

    Pixel Configuration

    1R1G1B

    Wavelength (R.G.B)

    R:625±2nm G:525±2nm B:470±2nm

    Drive Mode

    Static Drive Constant Current

    Cabinet Size

    960 × 640mm

    Cabinet Resolution

    60dots × 40dots

    Brightness

    ≥ 5,500cd/㎡

    Contrast

    ≥2000:1

    Viewing Angle

    140°(Horizontal )/140°(Vertical )

    Best Viewing Distance

    16-300m

    Grey Scale

    10bits/1024levels

    Color Capability

    16.7 million

    Color Temperature

    5,000-9,300K

    Maximum Power Consumption

    600 W/m2

    Average Power Consumption

    200 W/m2

    Working Voltage

    AC 220V/110V s±15% 50-60 HZ

    Frame Frequency

    60-85 HZ

    Refresh Frequency

    >1500HZ

    Brightness Correction

    Pixel, Module, Cabinet Correction

    Operating Temperature

    -40~+60℃

    Operating Humidity

    10-90% RH

    LED Lifespan

    100,000 hours

    MTBF

    ≥50,000 hours

    Computer Operation System

    Win 98/ Win XP/ Win 2000/Win7/Win 8

    Video Signal Input

    RF,S-Video, RGB,RGBHV,YUV,YC,VGA, DVI, HDMI, SDI,HD-SDI ,Composite

    Video Signal Output

    RF, S-Video, RGB, RGBHV, YUV, YC etc.

    Graphics Card

    DVI Graphics Card

    Control Distance

    LINSN / NOVA / DB-STAR

    Software

    LED studio 10.0

    OEM

    Yes

    Installation

    hung and stand

    Out of Control Rate

    0.01 %


    Our service:
    1. Any inquiry or complaint will be replied within 24hrs.
    2. Providing competitive products and sales consultation.
    3. Any your customized product or idea we can help you to design and put into product.
    4. Two-year quality guarantee, only needs to anew purchase the raw material when over the warranty period.
    5. Protection of your sales area, ideas of design and all your private information.
    6.Years of production experience we can very good to control the quality of the product, OEM and ODM accepted.

    Trade Terms :
    1. Packing: Anti-shaking wooden cabinet /Air flight case/carton
    2. Shipping port: Shenzhen. China
    3. Shipping freights are quoted according to your requests
    4. Delivery time:25 working days
    5. 2 years warranty ,lifelong maintaining. In the Maintenance period, free of all maintenance charges. After Maintenance period,only charge the material costs fees.
